GS Yuasa Dissolved Oxygen Sensor KDS-25B - KDS-25B
1) Long life
2) Virtually no influence from CO2
3) No external power supply required for sensor operation
4) No warmup time is required
- Model Number: KDS-25B
- Quantity:
- - +
Mouse over image to zoom
Product Specification
GS Yuasa Dissolved Oxygen Sensor KDS-25B
Features:
* Long life
* Virtually no in?uence from CO2
* No external power supply required for sensor
operation
* No warmup time is required
Applications:
* Water quality control
Specification:
| Item | Model | |
| KDS-25B | ||
| Measurement range | 0~80mg/L dissolved oxygen | |
| Accuracy in water at 25?C±1?C | ±5% (full scale) | |
| Operating conditions | Atmospheric pressure |
81~203kPa (corresponds to 10m of water depth) |
| Temperature | 5~35?C | |
| Relative humidity |
10 ~ 90%R.H. (no condensation) |
|
| Thermal time constant | 10 min. or less | |
|
Initial output voltage in clean air under standard test conditions |
8.0~15.0mV | |
| Standard test conditions | Atmospheric pressure | 1013±5hPa |
| Temperature | 25?C±1?C | |
| Relative humidity | 60±5% | |
The GS Yuasa Dissolved Oxygen Sensor KDS-25B is a unique galvanic cell type sensor which was developed for water quality control. Its most notable features are long life expectancy and it is not in?uenced by CO2.
